2.2 Outlook and parts’ names
(1) KDE11SS、KDE16SS、KDE13SS3、KDE20SS3
(2) KDE25SS、KDE30SS、KDE35SS、KDE30SS3、KDE35SS3、KDE45SS3、KDE60SS3、
KDE75SS3、KDE100SS3
1. Cabinet sidedoor 8. Lifting level
2. Cooling water inlet 9. Water outlet
3. Control panel door 10. Fuel outlet
4. Emergent stop button 11. Oil outlet
5. Output connection box 12. Slotted hole
6. Muffler exhaust 13. Fuel filling port of outer fuel tank
7. Fixed level
Water inlet
Exhaust
Output panel
Fuel inlet
Emergent stop button
Output panel
Fuel outlet
Water outlet
Fixed level
Lifting level
Oil outlet
