kobalttools.com
23
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-866-456-8934, 9 a.m. - 5 p.m.,
EST, Monday - Friday.
ITEM NO. PART NO. DESCRIPTION QTY
1 31104488-2 Upper handle assy. 1
2 33305469-9 Bail switch 1
3 31102489A-2 Motor engagement box 1
4 33309470 Lower handle 1
5 31102487-4 Cam lock assy. 4
6 341151161 Handle knob 2
7 3411135 Cord guide 1
8 341301337 Motor cover 1
9 32201110 Screw 1
10 33301488-3 Height adjustment plate 1
11 34202470 Dust plate 1
12 32204100 Self-lock nut M5 2
13 341311337 Housing 1
14 341071163 Handle 1
15 36101488 Motor 1
16 34105470-3 Cam lock cover 2
17 34106470 Cam lock base 2
18 341031506 Deck 1
19 341311337 Wheel cover 4
20 3290506 Washer 2
21 341021506 6” wheel 2
22 33301470-4
Front wheel axle 1
23 33307470 Clip 4
24 3320238A-1 Spindle bushing 1
25 34108488 Fan 1
26 33307468-2 16” blade 1
27 3410535 Blade insulator 1
28 3331435 Spacer 1
29 3221037 Nut M10X1.25 1
30 3290135 Pin 6
31 3290650 C-clip 3
32 33303470 Front link bar 1
33 33902470 Height adjustment spring 1
34 33201470 Height adjustment axle 1
35 33305470 Height adjustment bracket 1
36 33901470 Height adjustment torsional spring 1
37 33313470 Height adjustment lever 1
38 33306470 Clip 2
39 33304470 Rear link bar 1
40 34109470-1 Height adjustment handle 1
41 32201470 Screw 2
