CARE AND MAINTENANCE
2. REPLACING THE DRIVE BELTS
• Remove the 5 screws that secure the left side
cover (Q) to the frame of the snow thrower.
Remove the side cover.
2
5 Screws
Q
S
R
T
• Remove the old belt (R) from the small pulley
(S) and large pulley (T).
• Loop one end of the new belt over the small
pulley.
• Rotate the impeller with the left hand while
positioning the belt on the large pulley with the
right hand.
• Install the left side cover and secure it using
the 5 screws.
