Kobalt 2600503 User Manual

3
PART DESCRIPTION QUANTITY
A Upper chute control rod 1
B Lower chute control rod 1
C Middle handle 1
D Upper handle 1
E Chute deector 1
F Battery 1
G Charger 1
H Lower handle 1
I Discharge chute 1
J Handle of the chute
control rod
1
PACKAGE CONTENTS
A
B
C
D
E
F
G
PART DESCRIPTION QUANTITY
K Battery compartment
cover
1
L Battery release button 1
M Safety switch button 1
N Bail lever 1
O LED lights 1
P Trigger 1
Q Left side cover 1
R Drive Belt 1
S Small pulley 1
T Large pulley 1
H
I
J
K
L
M
N
O
P
S
R
T
Q

Kobalt 2600503 Specifications

General

Brand	Kobalt
Model	2600503
Category	Snow Blower
Language	English
