3
PACKAGE CONTENTS
PART DESCRIPTION PART DESCRIPTION
A Dust-protection cap F Direction-of-rotation selector
B Locking sleeve G Dust receptacle
C Mode selector H Auxiliary handle
D Variable-speed trigger switch I
Auxiliary handle recess
E Lock-on button J
Depth gauge
WARNING
• Remove the tool from the package and examine it carefully. Do not discard the carton or any
packaging material until all parts have been examined.
• If any part of the tool is missing or damaged, do not connect the plug to the power source or
use the tool until the part has been repaired or replaced. Failure to heed this warning could
result in serious injury.
A
B
C
F
E
D
G H
J
I
