3
PACKAGE CONTENTS
F
A
E D
KJI
C
L
B
HG
PART DESCRIPTION PART DESCRIPTION
A Trigger switch G Chain-tensioning knob
B Rear handle H Side cover
C Lock-off button I Guide bar
D Front handle J Saw chain
E Chain kickback brake handle K Oil-tank cap
F Side-cover knob L Chain sheath
WARNING
• Remove the tool from the package and examine it carefully. Do not discard the carton or
any packaging material until all parts have been examined.
• If any part of the tool is missing or damaged, do not attach the battery or use the tool until
the part has been repaired or replaced. Failure to heed this warning could result in serious
injury.
