3
PACKAGE CONTENTS
B
E
F
G
A
C
D H I J
PART DESCRIPTION
A Depth stop
B Screw scale
C Guide rail for screw strips
D Guide shaft for screw strips
E Screw-length-adjustment button
F Locking button
G Spring
H Display for screw-in depth
I Depth-adjustment dial
J Screwgun bit
WARNING
• Remove the tool from the package and examine it carefully. Do not discard the carton or any
packaging material until all parts have been examined.
• If any part of the tool is missing or damaged, do not attach the battery pack or use the tool
until the part has been repaired or replaced. Failure to heed this warning could result in
serious injury.
