Kobalt KPL 124B-03 User Manual

3
PACKAGE CONTENTS
PART DESCRIPTION PART DESCRIPTION
A Trigger switch J Wrench
B Lock-off button K Rear Base Plate
C Depth-adjustment Knob L Park Rest
D Depth-knob Scale M Blade
E Mounting thread N Blade Drum
F Front Plate O Bracket
G Rabbet-depth Guide P Edge guide
H Edge-guide Locking Knob (2) Q Dust Bag
I Dust/Chip-extraction Port
WARNING
• Remove the tool from the package and examine it carefully. Do not discard the carton or any
packaging material until all parts have been examined.
• If any part of the tool is missing or damaged, do not attach the battery to use the tool until
the part has been repaired or replaced. Failure to heed this warning could result in serious
injury.
A
B
C
D
O
Q
E
H
G
P
L
M
N
F
K
H
I
J
