Kobalt KT300A User Manual

7
OPERATING INSTRUCTIONS
1. To Attach Battery Pack
a. Place the direction-of-rotation selector (B) in the
center (locked) position.
b. Align the raised portion on the battery pack (G) with
the grooves on the bottom of the drill/driver, and then
slide the battery pack onto the drill/driver as shown.
c. Make sure that the latch on the battery pack snaps
into place and the battery pack is secured to the drill/
driver before beginning operation.
NOTICE: When placing the battery pack on the tool, be
sure that the raised rib on battery pack aligns with the
groove on the drill/driver and the latches snap into place
properly. Improper assembly of the battery pack can
cause damage to internal components.
To Detach Battery Pack (Fig. 1)
d. Make sure that the trigger switch (A) is in the “OFF”
position.
e. Press the battery-release button (H) to release the
battery pack.
f. Pull forward on the battery pack to remove it from the
drill/driver.
WARNING: Battery tools are always in operating
condition. Therefore, the direction-of-rotation selector
should always be locked (center) when the tool is not in
use or when carrying the tool at your side.
2. Trigger Switch
a. To turn the drill/driver ON, depress the trigger switch
(A). To turn it OFF, release the trigger switch.
Variable Speed
b. The variable-speed trigger switch delivers higher
speed with increased trigger pressure and lower
speed with decreased trigger pressure.
1
H
G
2
A
A
