8
INSTALLATION INSTRUCTIONS
WARNING
Risk of Personal Injury. Do not lift or move
unit without appropriately rated equipment.
Be sure the unit is securely attached to lifting
device used. Do not lift unit by holding onto
tubes or coolers. Do not use unit to lift other
attached equipment.
UNIT INSTALLATION
NOTICE
Unit Care and Maintenance. This compressor
is not intended for outdoor installation.
It is extremely important to install the compressor in a clean, well-ventilated area where the
surrounding air temperature will not be more than 100°F. Do not locate the compressor air inlet near
steam, paint spray, sandblast areas or any other source of contamination.
Estimated Installation and Assembly Time: 120 minutes
Tools Required for Installation and Assembly (not included): Safety Glasses; Work Gloves; 9/16 in.
Socket and Ratchet; Tape measure; Hammer Drill and Masonry Bit; Hammer; Phillips Screwdriver;
Flathead Screwdriver; Pipe Wrench; Two Adjustable Wrenches; 1/4 in. Nut Driver, Socket or Wrench;
240 Volt, 30 Amp Double Pole Circuit Breaker; Voltage Meter; Vibration Pads; 3/8 in. x 5 in. Wedge
Anchors (for concrete installation)
WARNING
Risk of Personal Injury. Do not operate unit
if damaged during shipping, handling or use.
Damage may result in bursting and cause
injury or property damage.
Before beginning installation and/or assembly of product, make sure all parts are present. Compare
parts with package contents list. If any part is missing or damaged, do not attempt to assemble or use
the product.
PREPARATION
kobalttools.com
