Kohler C3-325 User Manual

C³™-325
Elongated bidet toilet seat with remote control
K-28119
2-1/4"
(57 mm)
1"
(25 mm)
10-1/16"
(256 mm)
19-3/4"
(502 mm)
1-1/4"
(32 mm)
Min
7-7/8"
(200 mm)
11-15/16"
(303 mm)
6-11/16"
(170 mm)
21-1/4"
(540 mm)
5-1/2"
(140 mm)
13-1/4"
(337 mm)
Min
15-11/16" (398 mm)
16-3/8"
(416 mm)
1-1/2"
(38 mm)
2"
(51 mm)
6" (152 mm) Min
32" (813 mm) R.
Remote Control
Electrical Service Detail
Required Electrical Service
One dedicated circuit required, protected with Class A Ground-
Fault Circuit-Interrupter (GFCI). Outside North America, this
device may be known as a Residual Current Device (RCD).
Bidet toilet seat: 120 V, 15 A, 60 Hz
Technical Information
All product dimensions are nominal.
Seat shape type: Elongated
Seat front type: Closed-front
Seat-mounting
holes:
5-1/2" (140 mm)
Electrical component
rating:
Bidet toilet seat: 120 V, 15 A, 60 Hz,
1450 W
Power cord length: 51" (1295 mm)
Notes
Install this product according to the installation
guide.
To avoid possible product malfunction, do not
plug in the seat until instructed to do so.
CAUTION: Risk of property damage. A single
extension cord may be used provided the cord
“Type” begins with “SJ”, 12 gauge, grounded
(12/3), no longer than 25 feet, and plugged into
a GFCI outlet. Promptly replace any extension
cord that exhibits any sign of damage.
Connect the seat to a cold water supply of
drinking quality water at a pressure of 20 psi -
80 psi (139 kPa - 551 kPa).
Do not install this seat in a location where: (1)
water might be splashed on the product or
(2) excessive moisture, high humidity levels,
or condensation is present. This will avoid
damage to the electronic components.
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-6-2023 03:12 - US/CA/LM/MX
