Kohler Courage SV590 Service Manual

49
Emission Compliant Systems
20 690 01 Rev. F KohlerEngines.com
Remove Inlet Screen
Inlet Components
A
B
C
A Secondary Air Valve Assembly B Barb C Inlet Screen
1. Remove inlet screen from secondary air valve assembly by grasping inlet screen at base and gently pulling away
from valve assembly.
2. Use a soft brush to remove debris from screen.
3. Run water through inlet screen in reverse direction.
4. To reinstall, push inlet screen onto barb of secondary air valve assembly. An audible click will be heard when inlet
screen is properly reinstalled.

Kohler Courage SV590 Specifications

General

Compression Ratio	8.5:1
Power	19 hp
Fuel Type	Unleaded gasoline
Lubrication	Full pressure lubrication with full-flow filter
Starter Type	Electric
Engine Type	4-cycle, OHV, single cylinder
Displacement	597 cc
Ignition System	Electronic
Weight	32 kg
