6
Specifi cations
KohlerEngines.com 20 690 01 Rev. F
Model . . . . . . . . . . . . . . . . . . . . . SV470
Courage Engine
Vertical Shaft
Numerical Designation
Specifi cation . . . . . . . . . . . . . . . SV470-0001
Serial . . . . . . . . . . . . . . . . . . . . . 3923500328
Year Manufactured Code Factory Code
Code Year
39 2009
40 2010
41 2011
ENGINE IDENTIFICATION NUMBERS
Kohler engine identifi cation numbers (model, specifi cation and serial) should be referenced for effi cient repair,
ordering correct parts, and engine replacement.
GENERAL SPECIFICATIONS
3.6
SV470-SV480 SV530-SV540 SV590-SV620
Bore
Spec. 00XX:
Spec. 01XX:
Spec. 02XX or higher:
---
84 mm (3.30 in.)
89 mm (3.50 in.)
94 mm (3.70 in.)
---
89 mm (3.50 in.)
---
94 mm (3.70 in.)
94 mm (3.70 in.)
---
---
---
Stroke 86 mm (3.38 in.)
Displacement
Spec. 00XX:
Spec. 01XX:
Spec. 02XX or higher:
---
477 cc (29.1 cu. in.)
535 cc (32.6 cu. in.)
597 cc (36.4 cu. in.)
---
535 cc (32.6 cu. in.)
---
597 cc (36.4 cu. in.)
597 cc (36.4 cu. in.)
---
---
---
Oil Capacity (refi ll) 1.04-1.30 L (1.1-1.4 qt.)
Maximum Angle of Operation (@ full oil level)
4
25°
TORQUE SPECIFICATIONS
3,5
SV470-SV480 SV530-SV540 SV590-SV620
Air Cleaner Base
Hex Nut Fastener 5.5 N·m (48 in. lb.)
Mounting Screw Fastener (install dry) 8.0 N·m (70 in. lb.) into new hole
5.5 N·m (48 in. lb.) into used hole
Balance Weight
Screw 10.9-13.2 N·m (95.0-115.0 in. lb.)
Blower Housing and Sheet Metal
M6 Fastener 11.6 N·m (99 in. lb.) into new hole
7.7 N·m (68 in. lb.) into used hole
Cam Lever
Fastener 8.0-10.5 N·m (70-94.0 in. lb.) into new hole
7.1-8.6 N·m (61.8-74.8 in. lb.) into used hole
3
Values are in Metric units. Values in parentheses are English equivalents.
4
Exceeding maximum angle of operation may cause engine damage from insuffi cient lubrication.
5
Lubricate threads with engine oil prior to assembly.
6
Any and all horsepower (hp) references by Kohler are Certifi ed Power Ratings and per SAE J1940 & J1995 hp
standards. Details on Certifi ed Power Ratings can be found at KohlerEngines.com.
