1102602-A2-H 4 Kohler Co.
4.1 With Bracket
Drill 10 mm xing holes at the marked locations on the oor and insert the
anchor. Place a washer onto each of the hexagon screws and insert them in
the brackets. Fix the brackets to the oor. Position the toilet in the marked
position. install the sleeves using screws x the toilet to the brackets. Aach
the caps to the screw heads.
4 Floor xing - 2 methods
4.2 With Screw Only
Place the toilet into the desired position. place the protective plastic sleeve
onto the drill bit and, using the anchoring holes in the toilet as your guide,
drill 8 mm xing holes in the oor. place the anchors into the xing holes
through the toilet. Using the screws x the toilet to the oor. aach the caps
to the screw heads.
Anchor
