1102602-A2-H 6 Kohler Co.
Seat Installation
3 Connect the supply shut-o valve to the supply hose and connect supply hose
to toilet supply shank.
1 Install the seat as per the supplied
seat instructions.
2 Position the cistern on the pan by centering the gasket on the pan inlet. Ascemble
the retaining and sealing washer to the screw. Securely tighten the screw so the
cistern is level.
Screw
Plan Washer
Sealing Washer
Nut
Plastic Nut
Gasket
Screw
Retaining Washer
Plan Washer
Fiber Washer
Sealing Washer
Screw
Brass*
* Optional for different product
Brass*
Water
Hose
Water Supply Hose
(Not supplied)
