Kohler ESCALE User Manual

1102602-A2-H 8 Kohler Co.
Flush Valve Removal and Installation
2 Assembly ush valve by pushing
straight down into the canister and
turning left.
Flush Valve B
1
Release ush valve by squeezing
the tabs on both side of the canister
and pulling straight up out of the
ush valve.
2 Assembly ush valve by pressing it
into the ush valve so it snaps into
place.
Flush Valve A
1
Release ush valve by turning righ
and pull straight up on the canister.
1
2
1
2

Kohler ESCALE Specifications

General

Brand	Kohler
Model	ESCALE
Category	Plumbing Product
Language	English
