8. Connect the Electrical Supply
WARNING: Risk of electric shock. Disconnect the power
before performing the following procedures.
WARNING: Risk of electric shock. Connect only to a
properly grounded Ground-Fault Circuit-interrupter (GFCI)
or Residual Current Device (RCD) for protection against
line-to-ground shock hazard.
IMPORTANT! If you are unsure how to correctly connect the
power to the bowl consult a qualified electrician or service
technician. Improper power supply connection will lead to product
damage.
Remove the cover from the junction box on the toilet.
Connect the electrical wires.
The port labeled ″L″ is live.
The port labeled ″N″ is natural.
The bottom port is the ground.
Reinstall the cover.
L
N
Ground
Kohler Co. 13 1247364-2-A
