Kohler RDC2 Operation Manual

TP-6810 11/1346 Section 3 RDC2 Controller Operation
3.19 Load Control Menus
The generator set may be connected to a Load Control
Module (LCM) or a Model RXT transfer switch equipped
with a Load Shed kit. The Load Control menu displays
the status of the load control inputs and outputs, and
allows a test of the load control output relays.
Generator current is displayed as a percent of the
maximum generator capacity. The load control module
adds and sheds loads based on the generator current.
The test function cycles the relays in the order of their
priority.
For detailed information about load control operation,
refer to TT-1574, provided with the LCM kit, or TT-1609,
provided with the Load Shed kit.
Input 1:
In/Active
Output 1:
Add/Shed
Input 2:
In/Active
Output 2:
Add/Shed
Output 3:
Add/Shed
Output 4:
Add/Shed
Output 5:
Add/Shed
Output 6:
Add/Shed
Test Outputs
Push Select (blinking)
<---- Return
tp6810
Load ---->
Control
Load ---->
Control 1
<---- Return
Generator
Current: 123 %
Figure 3-23 Load Control Status Menu
