Foreword and general information
How to read electric wire code
28
HB205-1, HB215LC-100-28
How to read electric wire code
28
(Rev. 2010/11)
Hybrid
a The information about the wires unique to each hybrid machine model is described.
In the electric circuit diagram, the material, thickness, and color of each electric wire are indicated by symbols.
The electric wire code is helpful in understanding the electric circuit diagram.
1.
Type, symbol, and material
AV, AVS and AVSS are different in only thickness and outside diameter of the cover. AEX is similar to AV
in thickness and outside diameter of AEX and different from AV, AVS and AVSS in material of the cover.
CAVS is circular compressed conductor in conductor and different appearance from AV and AVS.
Example: AEX 0.85 L — Indicates blue, heat-resistant, low-voltage wire for automobile, having nominal No.
of 0.85
Indicates color of wire by color code.
Color codes are shown in Table 3.
Indicates size of wire by nominal No.
Size (Nominal No.) is shown in Table 2.
Indicates type of wire by symbol.
Type, symbol, and material of wire are shown in Table 1.
(Since the use of AV, AVS, AVSS, and CAVS wires depend on size (nominal No.),
their symbols are not indicated on the diagram.)
(Table 1)
Type Symbol Material
Using tempera-
ture range (°C)
Example of use
Low-voltage wire for
automobile
AV
Conductor
Annealed copper for electric
appliance
–30 to +60
General wiring (Nominal
No. 5 and above)
Insulator Soft polyvinyl chloride
Thin-cover
low-voltage wire for
automobile
AVS
AVSS
Conductor
Annealed copper for electric
appliance
AVS: General wiring (Nomi-
nal No. 3 to 5)
AVSS: General wiring
(Nominal No. 2)
Insulator Soft polyvinyl chloride
Heat-resistant
low-voltage wire for
automobile
AEX
Conductor
Annealed copper for electric
appliance
–50 to +110
General wiring in extremely
cold district, wiring at high
ambient temperature place
Insulator
Heat-resistant crosslinked
polyethylene
Compressed-conduct
or thin-cover
low-voltage wire for
automobile
CAVS
Conductor
Annealed copper for electric
appliance
–30 to +60
General wiring (Nominal
No. 0.5 to 1.25)
Insulator
Plasticized type polyvinyl
chloride
To Next Page
