TECHNICAL DATA 4
19
Screw, foot brake cylinder M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, front wheel speed sensor M6 4 Nm (3 lbf ft)
Screw, fuel pump M6 6 Nm (4.4 lbf ft)
Screw, license plate holder on
lower rear panel
M6 12 Nm (8.9 lbf ft)
Screw, radiator hose clip M6 3 Nm (2.2 lbf ft)
Screw, rear wheel speed sensor M6 4 Nm (3 lbf ft)
Screw, shift lever stub M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift rod M6 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, shift shaft deflector on shift
shaft
M6 18 Nm (13.3 lbf ft)
Loctite
®
243™
Screw, side stand stub M6 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, side stand stub extension M6 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, steering damper bracket on
frame
M6 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, step plate for foot brake
lever
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, suitcase molds M6 6 Nm (4.4 lbf ft)
Screw, tire pressure sensor
(Super Duke GT EU/US/CN)
M6 7 Nm (5.2 lbf ft)
Cable disk nut, exhaust valve M8 7 Nm (5.2 lbf ft)
Nut, manifold on cylinder head M8 Tightening sequence:
Tighten the nuts evenly. Do not
warp the metal plate.
25 Nm (18.4 lbf ft)
Nut, rear sprocket M8 36 Nm (26.6 lbf ft)
Nut, shift rod M8 12 Nm (8.9 lbf ft)
Nut, shift rod M8LH 12 Nm (8.9 lbf ft)
Nut, valve, angled
(Super Duke GT JP)
M8 4 Nm (3 lbf ft)
Nut, valve, angled (Super Duke GT
EU/US/CN)
M8 6 Nm (4.4 lbf ft)
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
Screw, axle clamp M8 15 Nm (11.1 lbf ft)
Screw, bottom triple clamp M8 15 Nm (11.1 lbf ft)
Screw, foot brake lever M8 20 Nm (14.8 lbf ft)
Loctite
®
243™
Screw, front brake disc M8 30 Nm (22.1 lbf ft)
Loctite
®
2701™
Screw, front rider footrest bracket M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
