WHEELS, TIRES 15
247
15.1 Removing the front wheel
Preparatory work
– Lift the motorcycle with the rear lifting gear. ( p. 199)
– Lift the motorcycle with the front lifting gear. ( p. 200)
S03926-10
Main work
–
Remove screws
1
from both brake calipers.
– Press back the brake linings by slightly tilting the brake
calipers laterally on the brake disc. Pull the brake calipers
carefully back from the brake discs and hang to the side.
Info
Do not operate the hand brake lever if the brake
calipers have been removed.
R01778-10
–
Loosen screw
2
and screws
3
.
–
Unscrew screw
2
about six turns and press your hand on the
screw to push the wheel spindle out of the axle clamp. Remove
screw
2
.
