4 TECHNICAL DATA - TIGHTENING TORQUES FOR CHASSIS 11

Screw, chain guard EJOT PT

4 Nm (3 lbf ft) –

Screw, headlight EJOT PT

4 Nm (3 lbf ft) –

Remaining screws, chassis M4 4 Nm (3 lbf ft) –

Screw, EFI control unit M4 4 Nm (3 lbf ft) –

Screw, trim, subframe, bottom M4 2 Nm (1.5 lbf ft) –

Remaining screws, chassis M5 5 Nm (3.7 lbf ft) –

Screw, ABS hose clamp

(Duke EU/MAL)

M5 8 Nm (5.9 lbf ft) –

Screw, brake fluid reservoir of rear

brake

M5 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, brake line holder, rear M5 8 Nm (5.9 lbf ft)

Loctite

243™

Screw, fuel pump M5 5 Nm (3.7 lbf ft) –

Screw, fuel tank closure flange M5 3 Nm (2.2 lbf ft) –

Screw, fuel tank cover M5 4 Nm (3 lbf ft) –

Screw, fuel tank trim M5 5 Nm (3.7 lbf ft) –

Screw, license plate holder M5 11 Nm (8.1 lbf ft) –

Screw, rollover sensor M5 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, side stand switch M5 5 Nm (3.7 lbf ft)

Loctite

243™

Screw, spoiler M5 5 Nm (3.7 lbf ft) –

Screw, subframe cover, bottom M5 5 Nm (3.7 lbf ft)

Loctite

243™

Screw, windshield M5 3 Nm (2.2 lbf ft) –

Nut, foot brake lever adjustment M6 10 Nm (7.4 lbf ft) –

Nut, radiator M6 5 Nm (3.7 lbf ft) –

Remaining nuts, chassis M6 15 Nm (11.1 lbf ft) –

Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –

Screw, air filter box M6 6 Nm (4.4 lbf ft) –

Screw, bottom of rear part M6 11 Nm (8.1 lbf ft) –

Screw, brake fluid reservoir of rear

brake

M6 9 Nm (6.6 lbf ft) –

Screw, cable holder, side stand switch M6 9 Nm (6.6 lbf ft)

Loctite

243™

Screw, chain sliding guard M6 9 Nm (6.6 lbf ft)

Loctite

243™

Screw, compensating tank M6 11 Nm (8.1 lbf ft) –

Screw, foot brake cylinder M6 9 Nm (6.6 lbf ft)

Loctite

243™

Screw, front fender M6 11 Nm (8.1 lbf ft) –

Screw, front seat fixing M6 5 Nm (3.7 lbf ft) –

Screw, fuel tank M6 11 Nm (8.1 lbf ft) –

Screw, headlight holder M6 11 Nm (8.1 lbf ft) –

Screw, headlight mask M6 11 Nm (8.1 lbf ft) –

Screw, ignition coil M6 9 Nm (6.6 lbf ft) –

Screw, license plate holder M6 14 Nm (10.3 lbf ft) –

Screw, magnetic holder on side stand M6 5 Nm (3.7 lbf ft)

Loctite

243™

Screw, radiator bracket M6 6 Nm (4.4 lbf ft) –

Screw, radiator holder M6 9 Nm (6.6 lbf ft) –

Screw, rear splash protector M6 9 Nm (6.6 lbf ft) –

Screw, rollover sensor holder M6 11 Nm (8.1 lbf ft) –

Screw, seat M6 11 Nm (8.1 lbf ft) –

Screw, shift activation M6 11 Nm (8.1 lbf ft)

Loctite

243™

Screw, voltage regulator M6 10 Nm (7.4 lbf ft) –

Screw, voltage regulator holder M6 15 Nm (11.1 lbf ft) –

Screw, wheel speed sensor holder

(Duke EU/MAL)

M6 8 Nm (5.9 lbf ft) –

Remaining nuts, chassis M8 30 Nm (22.1 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –
