Exploded View
Disassembly &
Assembling
Workshop manual
4860 MXMA
4
Frontfork 4860
MXMA
2003
05/2002
Note the
rebound
position
by
turning
the
knob to
the
right.
After removing
the
rubber
cap.
Note the
compression
position
by
turning the
screw
to
the
right.
Clamp the
outer-tube
in
T1403S
and
unscrew the
screw-c
ap P
A with
T103.
12_063
Disassembly forkleg
12_062
263
265
Table of Contents
