23 TECHNICAL DATA 107

Screw, locking lever M5 6 Nm (4.4 lbf ft) Loctite

243™

Screw, oil pump cover M5 6 Nm (4.4 lbf ft) Loctite

243™

Screw, stator M5 6 Nm (4.4 lbf ft) Loctite

243™

Nut, cylinder head M6 10 Nm (7.4 lbf ft) Lubricated with engine oil

Nut, water-pump wheel M6 6 Nm (4.4 lbf ft) Loctite

243™

Screw, alternator cover M6 6 Nm (4.4 lbf ft) –

Screw, clutch cover M6 10 Nm (7.4 lbf ft) –

Screw, clutch slave cylinder M6 10 Nm (7.4 lbf ft) –

Screw, engine case M6 10 Nm (7.4 lbf ft) –

Screw, exhaust flange M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, kick starter stop M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, oil filter cover M6 10 Nm (7.4 lbf ft) –

Screw, shift drum locating M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, shift lever M6 14 Nm (10.3 lbf ft) Loctite

243™

Screw, starter motor M6 10 Nm (7.4 lbf ft) –

Screw, timing chain guide rail M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, timing chain securing guide M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, valve cover M6 8 Nm (5.9 lbf ft) –

Screw, water pump cover M6 10 Nm (7.4 lbf ft) –

Stud, cylinder head M6 10 Nm (7.4 lbf ft) –

Screw, camshaft bearing bridge M7x1 14 Nm (10.3 lbf ft) Lubricated with engine oil

Screw plug, crankshaft location M8 10 Nm (7.4 lbf ft) –

Screw, kick starter M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, timing chain tensioning rail M8 15 Nm (11.1 lbf ft) Loctite

243™

Screw, engine sprocket M10 60 Nm (44.3 lbf ft) Loctite

2701™

Plug, oil channel M10x1 15 Nm (11.1 lbf ft) Loctite

243™

Rotor screw M10x1 70 Nm (51.6 lbf ft) Thread, oiled with engine

oil/cone degreased

Screw plug, cam lever axis M10x1 10 Nm (7.4 lbf ft) –

Screw, unlocking of timing chain ten-

sioner

M10x1 10 Nm (7.4 lbf ft) –

Spark plug M10x1 10… 12 Nm (7.4…

8.9 lbf ft)

–

Nut, cylinder head M10x1.25 Tightening sequence:

Tighten diagonally.

1st tightening stage

10 Nm (7.4 lbf ft)

2nd tightening stage

30 Nm (22.1 lbf ft)

3rd tightening stage

50 Nm (36.9 lbf ft)

Thread, oiled with engine

oil/cone greased

Stud, cylinder head M10x1.25 20 Nm (14.8 lbf ft) Loctite

243™

Screw, camshaft drive sprocket M12x1 70 Nm (51.6 lbf ft) Loctite

243™/cone

degreased

Engine coolant temperature sensor M12x1.5 12 Nm (8.9 lbf ft) –

Oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft) –

Plug, oil pressure regulator valve M12x1.5 20 Nm (14.8 lbf ft) –

SAS screw plug M12x1.5 20 Nm (14.8 lbf ft) –

Oil drain plug M14x1.5 15 Nm (11.1 lbf ft) –

Nut, SAS valve M16 15 Nm (11.1 lbf ft) –

Nut, inner clutch hub M18x1.5 100 Nm (73.8 lbf ft) Loctite

243™

Nut, primary gear M18LHx1.5 100 Nm (73.8 lbf ft) Loctite

243™

Screw plug, oil screen M20x1.5 15 Nm (11.1 lbf ft) –

Plug, timing chain tensioner M24x1.5 25 Nm (18.4 lbf ft) –

Screw, alternator cover M24x1.5 18 Nm (13.3 lbf ft) –
