Seat lock, removing the seat
The seat lock [2] can be locked with the ignition key.
To remove the seat, insert the ignition key and turn 45° in a counterclockwise direction. Lift
the seat in the back, pull back and lift off.
To mount the seat, attach the seat to the oval head screw [3], lower the seat in the back
while sliding it towards the front. Both noses [4] should fit into the frame. Insert the catch
bolts [5] in the lock housing and push the seat down in the back until you hear the catch
bolts snap into place.
Check whether the seat is correctly mounted.
If not correctly mounted, the seat can slip while you are driving and cause you to lose con-
trol of your motorcycle.
OPERATION INSTRUMENTS »
15
Grips
The grips [1] are used to maneuver the motorcycle. If carrying a passenger, the passenger
can hold on to the grip during the ride.
