WORK 3
17
3.5 Installing the start number plate
F01525-10
–
Position the brake line in holders
A
on the start number
plate.
–
Position the start number plate. Mount and tighten screw
1
.
The holding lugs engage in the fender.
3.6 Removing the seat
Caution
Danger of burns The voltage regulator gets very hot when the vehicle is driven.
– Allow the voltage regulator to cool down before performing any work.
F01533-10
–
Remove screw
1
.
H02218-10
– Raise the rear of the seat, pull the seat back, and lift it off.
3.7 Mounting the seat
H02218-11
– Mount the front of the seat on the collar bushing of the fuel
tank, lower the seat at the rear, and push the seat forward.
– Make sure the seat is latched in place correctly.
