25SPECIFICATIONS
ENGLISH
SPECIFICATIONS
A Specifications are subject to change without notice.
A This CO
2
measurement results from testing over a fixed test cycle under laboratory conditions a(n) (parent) engine
representative of the engine type (engine family) and shall not imply or express any guarantee of the performance
of a particular engine.
Model D1005-E4 D1105-E4
Type Vertical, water-cooled, 4-cycle diesel engine
Number of cylinders 3
Bore and stroke mm (in.) 76 × 73.6 (2.99 × 2.90) 78 × 78.4 (3.07 × 3.09)
Total displacement cm (cu.in.) 1001 (61.08) 1123 (68.53)
Combustion chamber Spherical Type (E-TVCS)
SAE NET Intermittent kW / rpm
H.P. (SAEJ1349) (HP / rpm)
17.7/3200
(23.7/3200)
17.8/3000
(23.9/3000)
SAE NET Continuous kW / rpm
H.P. (SAEJ1349) (HP / rpm)
15.4/3200
(20.6/3200)
15.4/3000
(20.7/3000)
Maximum bare speed rpm 3420 3220
Minimum bare idling speed rpm 1300
900
Order of firing 1-2-3
Direction of rotation Counter-clockwise (viewed from flywheel side)
Injection pump Bosch MD Type Mini Pump
Injection pressure 13.73 Mpa (140 kgf/cm , 1991 psi)
Injection timing (Before T.D.C.) 20° 18°
Compression ratio 24 : 1
Fuel Diesel Fuel No.2-D (ASTM D975)
Lubricant
(API classification)
above CF grade
Dimension mm (in.)
(length × width × height)
497.8 × 396.0 × 602.0
(19.60 × 15.59 × 23.7)
Dry weight
(BB Spec.) kg (lbs.)
93
(205.0)
Starting system Cell starter (with glow plug)
Starting motor 12 V, 1.2 kW
Charging generator 12 V, 480 W
Recommended battery capacity 12 V, 65 AH, equivalent
EU engine family name HKBXL01.5BCB HKBXL01.5BCB
CO
2
Emission data g/kWh
Non-road steady-state test cycle
1018.0 1018.0
