6 OPERATING THE ENGINE
ENGLISH
STOPPING THE ENGINE CHECKS DURING OPERATION
While running, make the following checks to see that all
parts are working correctly.
BRadiator Cooling water(Coolant)
WARNING
To avoid personal injury:
A Do not remove radiator cap until
coolant temperature is well below
its boiling point. Then loosen cap
slightly to the stop position, to
relieve any pressure, before
removing cap completely.
When the engine overheats and hot coolant overflows
through the overflow pipe and cannot be stopped, stop
the engine immediately and make the following checks
to determine the cause of trouble:
Check item
1. Check to see if there is any coolant leak;
2. Check to see if there is any obstacle around the
cooling air inlet or outlet;
3. Check to see if there is any dirt or dust between
radiator fins and tube;
4. Check to see if the fan belt is too loose;
5. Check to see if radiator water pipe is clogged; and
6. Check to see if anti-freeze is mixed into coolant in
warm seasons.
BOil pressure lamp
The lamp lights up to warn the operator that the engine
oil pressure has dropped below the prescribed level. If
this should happen during operation or should not go off
even after the engine is accelerated more than
1000rpm, immediately stop the engine and check the
following:
1. Engine oil level (See "ENGINE OIL" in "PERIODIC
SERVICE" section.)
2. Lubricant system (See "ENGINE OIL" in "PERIODIC
SERVICE" section.)
1. Return the speed control lever to low
idle, and run the engine under idling
conditions.
2. Set the engine stop lever to the "STOP"
position.
3. With the key switch placed to the
"SWITCHED OFF" position, remove the
key. (Be sure to return the engine stop
lever to the "START" position to be
ready for the next start.)
(1) Speed control lever
(2) Engine stop lever
(A) "IDLING"
(B) "OPERATION"
(C) "START"
(D) "STOP"
