Kubota L3200 User Manual

5IMPLEMENT LIMITATIONS
A Implement size may vary depending on soil operating conditions.
No. Implement Remarks L3200 L3800
1Trailer
Max. load capacity kg 1000
Max. drawbar load kg 330
2 Mower
Rotary-Cutter
Max. cutting width mm 1829
Max. weight kg 350
Flail Mower
Max. cutting width mm 1270
Max. weight kg 350
Sickle Bar
Max. cutting width mm 1829
Max. weight kg 400
3 Sprayer
Rear mounted Max. tank capacity L 300
Pull type Max. tank capacity L 800
4 Rotary Tiller Max. tilling width mm 1370
5 Bottom Plow Max. size 12 in. x 2, 16 in. x 1
6 Disk harrow : Pull type
Max. harrowing width mm 1524
Max. weight kg 300
7 Chisel Plow
Max. width mm 1829
Max. weight kg 350
8 Broad Caster
Max. tank capacity L 200
Max. weight kg 100
9 Manure Spreader Max. capacity kg 1000
10 Cultivator
Max. width mm 1524
Number of rows 1
Max. weight kg 250
11 Front Blade
Max. cutting width mm 1829
Max. oil pressure MPa (kgf/cm ) 15.9 (162.1)
Sub frame Necessary
12 Rear Blade
Max. cutting width mm 1829
Max. oil pressure MPa (kgf/cm ) 15.9 (162.1)
13 Front-end Loader
Max lifting capacity kg 460
Max. oil pressure MPa (kgf/cm ) 15.9 (162.1)
Sub frame Not necessary
14 Box Blade
Max. cutting width mm 1321
Max. weight kg 315
15 Backhoe
Max. digging depth mm 2288
Max. weight kg 420
Sub frame Necessary
16 Snow Blade
Max. width mm 1524
Max. weight kg 300
17 Snow Blower
Max. working width mm 1524
Max. weight kg 250

Kubota L3200 Specifications

General

Engine Type	Diesel
Drive	4WD
Hydraulic System	Open center
3-Point Hitch	Category I
Engine Power	31.9 HP
Number of Speeds	8 forward and 4 reverse
PTO Horsepower	25.5 HP
Engine Model	D1703-M
Width	55.1 inches
Height	91.7 inches
