PERIODIC SERVICE50
C How to read the indicator
Check the battery condition by reading the indicator.
C Battery Cable Connections
1. Be sure to wire the battery cable as shown in the
figure.
2. Fix the positive cable in the cord band.
3. Tighten the terminal until the stopper comes in
contact.
C Battery Charging
To avoid personal injury:
A When the battery is being activated, hydrogen
and oxygen gases in the battery are extremely
explosive. Keep open sparks and flames away
from the battery at all times, especially when
charging the battery.
A When charging the battery, ensure the vent
caps are securely in place. (if equipped)
A When disconnecting the cable from the battery,
start with the negative terminal first.
When connecting the cable to the battery, start
with the positive terminal first.
A Never check battery charge by placing a metal
object across the posts.
Use a voltmeter or hydrometer.
1. To slow charge the battery, connect the battery
positive terminal to the charger positive terminal and
the negative to the negative, then recharge in the
standard fashion.
2. A boost charge is only for emergencies. It will partially
charge the battery at a high rate and in a short time.
When using a boost-charged battery, it is necessary to
recharge the battery as early as possible.
Failure to do this will shorten the battery's service life.
3. The battery is charged if the indicator display turns
green from black.
4. When exchanging an old battery for a new one, use
battery of equal specification shown in table 1.
Table 1
CCA : Cold Cranking Ampere
(1) Battery
(2) Indicator
State of indicator display
Green
Specific gravity of electrolyte and quality of
electrolyte are both in good condition.
Black Needs charging battery.
White Needs replacing battery.
(1) Negative cable
(2) Positive cable
(3) Cord band
(4) Terminal
(5) Stopper
(1) Battery
Battery
TYPE
volts
(V)
Reserve
capacity
(min)
CCA
(SAE)
(A)
Normal
Charging
Rate (A)
75D26R 12 123 490 6.5
