SPECIFICATIONS
1. BX tractor specifications
Model BX23S
PTO power
*1
13.2 kW (17.7 HP)
Engine
Maker KUBOTA
Model D902
Type Liquid-cooled, 4-cycle diesel
Number of cylinders 3
Bore and stroke 72.0 × 73.6 mm (2.83 × 2.90 in.)
Total displacement 898 cm
3
(54.8 cu. in.)
Engine gross power
*2
17.1 kW (23.0 HP)
Rated revolution 55.0 to 58.3 r/s (3300 to 3500 rpm)
Low idling revolution 1350 to 1550 rpm
Maximum torque 56.1 N⋅m (41.4 lbf⋅ft)
Battery 12 V, CCA: 560 A, RC: 86 min.
Fuel
Diesel fuel No.1 [below -10 ℃ (14 ℉)]
Diesel fuel No.2 [above -10 ℃ (14 ℉)]
Capacities
Fuel tank 25 L (6.6 U.S.gals.)
Engine crankcase (with filter) 3.3 L (3.5 U.S.qts.)
Engine coolant 3.1 L (3.3 U.S.qts.)
Recovery tank 0.4 L (0.4 U.S.qts.)
Transmission case 11.3 L (2.99 U.S.gals.)
Dimensions
Overall length (without 3p) 2210 mm (87.01 in.)
Overall length (with 3p) 2515 mm (99.02 in.)
Overall width (Min. tread) 1145 mm (45.08 in.)
Overall height
(with ROPS) 2190 mm (86.22 in.)
(Top of seat) 1255 mm (49.41 in.)
Wheel base 1400 mm (55.12 in.)
Min. ground clearance 148 mm (5.83 in.)
Tread
Front 930 mm (36.6 in.)
Rear 820 mm (32.2 in.)
Weight (with ROPS) 725 kg (1600 lbs)
Clutch N/A
Traveling system
Tire
Front: Turf/Bar/industrial 18 × 8.50-10
Rear: Turf/Bar/industrial 26 × 12.00-12
Steering Hydrostatic type power steering
Transmission
Main: Hydrostatic transmission, High-Low
gear shift (2 forward, 2 reverse)
(Continued)
SPECIFICATIONS
1.BX tractor specifications 1. INFORMATION
BX23S, LA340, BT603, RCK54D, RCK60D, RCK54, RCK60B
