Charging
socket 24V
5. Recharging and Battery
5.1 Recharging Battery
Complete the following procedures:
1. Turn the charger power switch to
"OFF" (as shown in the right figure)
2. Connect the
round pin of
"24V output
cable" of charger to the charging
socket under the joystick of 3.
Connect the "220V cable" to the
"charger socket and household
socket".
4. Turn the charger "ON" (see right figure)
5. The charging process starts when the red power
indicator of the charger and orange charging indicator
light up.
The charging process normally lasts for 8 hours,
sometimes it may become 8~12 hours (the battery
status is related to the temperature of
environment, refer to 5.4 "Battery").
6. The charging process is complete
when the charging indicator turns from
orange to green.
7. Turn off the charger and remove the "24V output
cable" from the charging socket.
