Kyocera ECOSYS M3645idn User Manual

5-38
Operation on the Machine > Basic Operation for Document Box
Sub Address Box/Polling Box/FAX Memory RX Box
Sub Address Box/Polling Box store the fax data.
FAX Operation Guide
Basic Operation for Document Box
This section explains basic operations for document boxes, using examples where tasks are carried out with custom
boxes.
Box List Operations
Document List Operations
The document list is a list of the documents stored in the custom box. The operations below are available.
NOTE
In the following explanation, it is assumed that user login administration is enabled. For details on User Logon
privileges, refer to the following:
Editing and Deleting Custom Box (page 5-41)
1 This opens the selected box.
2 You can select [Menu] and then perform one
of the following operations: search for a
Document Box search (box name, box
number), change the sorting sequence of
display items (box name, box number,
owner), register a new box, modify or delete
a box.
3 This displays detailed information about each
box.
1 A check mark indicates an item is selected.
2 You can select [Menu] and then perform one
of the following operations: print, move,
search for (by name), edit, or delete a
document, select or deselect all, change the
sorting sequence of display items (name,
box number, owner)
3 Shows detailed information about the
document.
4 Can be used for a document name search.
NOTE
• You can select multiple documents by pressing the respective document checkboxes.
• Select [ ] to change to list display.
Custom Box
10:10Document Box.
Box 01
Next >Menu
No Owner
1/1
0001
1
3
2
Box:Box01
10:10Document Box.
< Back PrintMenu
1/1
Cancel
1
2
3
4

Kyocera ECOSYS M3645idn Specifications

General

N-up printing	2, 4
Duplex printing	Yes
Print technology	Laser
Borderless printing	No
Duplex printing mode	Auto
Time to first page (black, normal)	5.9 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Duplex print speed (black, normal quality, A4/US Letter)	22.5 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	7 s
Copy speed (black, normal quality, A4)	45 cpm
Scan to	E-mail, FTP, SMB, TWAIN, USB, WIA
Scan drivers	TWAIN, WIA
Grayscale levels	256
Maximum scan area	216 x 356 mm
Scan speed (black)	60 ppm
Scan speed (color)	40 ppm
Image formats supported	JPEG, TIFF
Duplex scan speed (black)	26 ppm
Duplex scan speed (color)	17 ppm
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	256 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	400 x 400 DPI
Fax transmission speed	3 sec/page
Printing colors	Black
Duplex functions	Copy, Fax, Print, Scan
Maximum duty cycle	25000 pages per month
Recommended duty cycle	3000 - 10000 pages per month
Replacement cartridges	TK-3060 (14.500 pagina's)
Number of print cartridges	1
Page description languages	OpenXPS, PCL 6, TIFF, XPS
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	3
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	50 W
Power consumption (sleep)	0.5 W
Power consumption (copying)	652 W
Power consumption (printing)	630 W
Energy Star Typical Electricity Consumption (TEC)	2.38 kWh/week
Processor cores	2
Processor family	ARM Cortex-A9
Coprocessor frequency	1.2 GHz
Card reader integrated	-
Compatible memory cards	SD, SDHC
Maximum internal memory	3000 MB
Sound power level (standby)	30 dB
Sound pressure level (copying)	54 dB
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	250 sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Paper tray media types	Plain paper
Non-ISO print media sizes	Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Envelopes, Labels, Legal, Letter, Plain paper, Recycled paper, Thick paper, Thin paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	15 - 80 %
Sustainability certificates	Blue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Certification	TÜV/GS, CE, ISO 9001, ISO 14001.
Package depth	572 mm
Package width	589 mm
Package height	695 mm
Package weight	29800 g
Cables included	AC
Included cartridge capacity (black)	6000 pages
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	476 mm
Width	475 mm
Height	575 mm
