Kyocera ECOSYS MA4500x User Manual

8-48
Setup and Registration (System Menu) > System Menu
Document Box
[System Menu/Counter] key > [ ] [ ] key > [Document Box] > [OK] key
Configures settings related to the Custom Box, Job Box, Sub Address Box and Polling Box.
Item Description
Custom Box Configure settings for Custom Box.
Detail/Edit
Creating a New Custom Box (page 5-36)
File Del. Time Set the time to automatically delete stored documents.
Value: Hour (00 to 23), Min. (00 to 59)
Sub Address Box
*1
*1 Only on products with the fax function installed.
FAX Operation Guide
Job Box Configure settings for Job Box.
Quick Copy Jobs To maintain free space on the box, you can set the maximum number of stored jobs.
Value: number between 0 and 300
NOTE
When 0 is set, Quick Copy cannot be used.
JobRet. Deletion This setting specifies that documents, such as Private Printing, Quick Copying, or Proof
and Hold Printing, saved temporarily in the job box are automatically deleted after they
have been saved for a set time.
Value: Off, 1 hour, 4 hours, 1 day, 1 week
NOTE
This function is valid for documents saved after the function is set. Regardless of this
function setting, temporary documents are deleted when the main power switch is
turned off.
DelPIN at PwrOff Configures whether to delete the jobs retained in the PIN Print box when the power is
turned off.
Value: Off, On
Storage Media Select which storage media to use.
Value: SSD, SD Card
NOTE
This setting is not displayed if the optional SSD or SD card is not installed.
Polling Box
*1
FAX Operation Guide
Select Key Set. Commonly used printing and storing functions can be registered to the Select key.
Functions used when printing and when saving can both be registered. Functions can be
easily configured by selecting the Select key.
Value
Print: None, Quiet Mode, Collate
*2
, Paper Selection
*2
, Duplex
*2
, EcoPrint
*2
,
File Name Entry, JobFinish Notice, Print Override, Encrypted PDF
*3
, JPEG/
TIFF Print
*3
, XPS FitTo Page
*3
, Del. after Print
*4
Store: None, Quiet Mode, Color Selection
*5
, Original Size, Original Image,
Scan Resolution, Storing Size
*5
, Zoom
*5
, Orig. Orientation, Mixed Size Org.
*5
,
Continuous Scan, Long Original, File Format
*5
, File Separation
*5
, File Name Entry,
JobFinish Notice, Density, Duplex, Sharpness
*5
, Contrast
*5
, Backgrnd Density
*5
,
Prevent Bleed-t
*5
, Skip Blank Page
*2 Only displayed when printing from USB drive and Custom Box.
*3 Only displayed when printing from USB drive.
*4 Only displayed when printing from Sub Address Box and Custom Box.
*5 Not displayed when saving to Polling Box.

Kyocera ECOSYS MA4500x Specifications

General

N-up printing	2, 4, 6, 8, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.3 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Duplex print speed (black, normal quality, A4/US Letter)	22.5 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	6 s
Copy speed (black, normal quality, A4)	45 cpm
Scan to	E-mail, FTP, Fax, File, Image, Memory Card, PC, SMB, TWAIN, USB, WIA
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Maximum scan area	210 x 297 mm
Scan speed (black)	60 ppm
Scan speed (color)	40 ppm
Image formats supported	JPEG, TIFF
Duplex scan speed (black)	26 ppm
Duplex scan speed (color)	17 ppm
Document formats supported	PDF, XPS
Optical scanning resolution (black)	600 x 600 ppi
Optical scanning resolution (color)	300 x 300 ppi
Faxing	No
Printer fonts	Barcode, Bitmap, PCL
Printing colors	Black
Duplex functions	Copy, Print, Scan
Country of origin	Vietnam
Maximum duty cycle	150000 pages per month
Recommended duty cycle	3000 - 15000 pages per month
Replacement cartridges	TK-3400
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCL XL, PDF 1.4
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	2600 sheets
Paper tray 1 input capacity	500 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Custom media width	140 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	210 - 356 mm
Paper tray media types	Banner, Letterhead, Plain paper, Pre-Printed, Thicker paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-Purpose Tray media weight	60 - 220 g/m²
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Kyocera Mobile Print, Mopria Print Service
Processor family	ARM Cortex-A5
Compatible memory cards	SD
Maximum internal memory	3000 MB
Sound pressure level (standby)	30 dB
Sound pressure level (printing)	54 dB
Display	LCD
Control type	Buttons
Product color	Black, White
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	Blablabla W
Power consumption (off)	0.1 W
Power consumption (ready)	55 W
Power consumption (sleep)	0.5 W
Power consumption (copying)	585 W
Power consumption (standby)	38 W
Power consumption (printing)	602 W
Energy Star Typical Electricity Consumption (TEC)	0.62 kWh/week
Mac operating systems supported	Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Package depth	570 mm
Package width	607 mm
Package height	695 mm
Package weight	30000 g
Cables included	AC
Included cartridge capacity (black)	6000 pages
Operating altitude	0 - 3500 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	15 - 80 %
Sustainability certificates	REACH, RoHS, Turkish Environment Label

Weight and Dimensions

Depth	476 mm
Width	475 mm
Height	575 mm
