Chapter 3: Getting Started
Product Service 1-800-522-7658
9
Work Surface and Enclosure Installation
1. Level the base cabinets and the work surface. Work surface should be
placed flush with the front of the stand or base cabinet as shown in
Figure 3-1.
2. Identify and position the work surface ensuring the mounting holes
will align with the four screw locations on the base of the enclosure.
(Rear mounting holes are located close to the rear edge.)
3. Secure the work surface to the base cabinet with a structural adhesive
or silicone sealant.
4. Before moving the enclosure, insert the supplied mounting screws in
the four holes. Allow a minimum of 1/8" clearance under the head of
the screw for positioning the enclosure. For the stainless work
surfaces, use a #10-24 x 3/8" hex washer head screw (Labconco part
number 1885806).
5. Place the enclosure on the work surface and slide the rear flange and
front air foil flanges under the mounting screw heads.
6. Tighten the four screws to complete the installation.
7. If desired, apply RTV silicone to seal the work surface and enclosure.
