10 / 30 Puridest Distillation Apparatus 09/2020
Distillate withdrawal j
6.1
Distillate is withdrawn from the unit through the black plastic tap on the front of the unit. It can be opened in continuous
or interval positions. A laboratory hose with an inner diameter of approx. 15 mm can be connected to the tap, the hose
has to be secured from slipping off with a hose clip.
Caution:
The distillate leaves the Distillation Apparatus with a temperature of more than 50 °C.
Danger of scaldings!
Drain boiler k
6.2
Connect a ½" hose to drain the boiler when cleaning the unit and/or carrying out maintenance works.
Caution:
the water leaves the boiler of the Distillation Apparatus with a temperature of up to 100 °C.
Danger of scaldings!
Cooling water outlet l
6.3
Connect a ¾" temperature-resistant hose to the cooling water outlet. It may have a maximum length of approx. 1.5 m. It
must be led into an open drain on a lower level and must have a slope on its complete length.
Make sure the cooling water can drain without back draughts.
Caution:
cooling water leaves the Distillation Apparatus with a temperature of up to 70 °C.
Danger of scaldings!
Tap water inlet m
6.4
The tap water inlet supplies water to the Distillation Apparatus through a solenoid valve. The hose connection of the valve
must be connected with the water mains through a ½" pressure hose and a blockable water connection (⑤, hand stop
valve).
It is absolutely essential to use hose clips to secure both hose connections!
