14 Connection to the mains supply
The electrical connection must ensure an all-pole separation of the Bi Distillation Apparatus from the mains supply. In-
stalled assembly parts, such as CEE shock-proof sockets or main switches, must be installed so as to ensure clear identifi-
cation and they must be within easy reach in an emergency case. All Bi Distillation Apparatus must have a permanent
connection with the mains. This may only be implemented through an on-site main switch or through a CEE plug in con-
formity with IEC standard 60309-2 (see examples for connection to the mains in chapter 14).
Colour decoding of the individual leads of the mains connection cables for Bi Distillation Apparatus.
Colour decoding
Model PD 2 D
Mains supply
230 V / 1 ~ / N / PE
50 / 60 Hz
Model PD 4 D, PD 8 D
Mains supply
220 V / 3 ~ / N / PE
50 / 60 Hz
Model PD 4 D, PD 8 D
Mains supply
400 V / 3 ~ / N / PE
50 / 60 Hz
ge/gr
–
yellow/green
PE (
Protective earth
)
PE (
Protective earth
)
PE (
Protective earth
)
bl
–
blue
N
N
sw
–
black
L1
L1
br
–
brown
L
L2
L2
gra
–
grey
L3
L3
Bi Distillation Apparatus can be supplied in different versions for connection to different mains supplies.
Model PD 2 D is only available for connection to 230 V AC (see nameplate) and can be connected to all mains supplies
with 220 V or 230 V.
Models PD 4 D and PD 8 D for connection to 220 V / 3 ~ (see nameplate) can only be connected to mains supplies with
220 V / 3 ~ / PE.
Models PD 4 D and PD 8 D for connection to 400 V / 3 ~ (see nameplate) can only be connected to mains supplies with
400 V / 3 ~ / N / PE.
On-site electrical fuses
Model
Power
Power consumption at mains voltage
On
-
site mains fuse
(F2
–
F
4
)
PD 2
D
3
.
5 kW
15.
2
A
at
230 V
16
A
PD 4 D 7.0 kW 18.0 A at 220 V / 3 ~ / PE
13
.
0 A
at
400 V / 3
~
/ N / PE
20 A
16 A
PD 8 D 11.0 kW 30.2 A at 230 V / 3 ~ / PE
16
.
6
A
at
400 V / 3
~
/ N / PE
35 A
2
0 A
* see nameplate
