Launch CRP 349 User Manual

7
LAUNCH CRP 349 User Manual
EN
3. Product Descriptions
3.1 Outline of CRP 349
Figure 3-1
No. Name Descriptions
1 Charging LED
Red means Charging and Green means Fully
charged.
2 LCD Indicates test results.
3
DB-15 diagnostic
connector
To connect to vehicle's DLC (Data Link Connector)
via diagnostic cable.
4 5V Charging port
To connect to external DC power for charging the
tool.

Launch CRP 349 Specifications

General

Brand	Launch
Model	CRP 349
Category	Diagnostic Equipment
Language	English
