Leica T-Scan 5 Quick Guide

7 Operation
The first installation of the product should be done by authorised Leica Geosys-
tems personnel. Installation by unauthorised personnel may cause damage and
will make the warranty null and void.
Setting up and connecting the T‑Scan system components
1. Set up the Absolute Tracker system according to the instruction given
in the Absolute Tracker User Manual.
2. Connect the T‑Scan sensor cable to the connector marked with "Scan-
ner" on the rear panel of the T‑Scan controller.
3. Connect the Trigger/Probe cable to the connector marked with
"Tracker" on the rear panel of the T‑Scan controller and to the trigger/
probe connector of the Absolute Tracker controller.
4. Connect a LAN cable to the RJ45 connector on the rear panel of the
T‑Scan controller as well as of the Absolute Tracker controller.
5. Connect a second LAN cable to the other connector of the T‑Scan con-
troller and to a connector of the application computer.
6. Connect the provided AC power supply to the T‑Scan controller and to
the grounded mains socket outlet. Alternatively connect a MPB25 bat-
tery to the T‑Scan controller.
General
Step-by-step
22 Operation

Leica T-Scan 5 Specifications

General

Brand	Leica
Model	T-Scan 5
Category	GPS
Language	English
