SPECIFICATIONS
General
Data
Model No. 13ACX−018
13ACX−024 13ACX−030 13ACX−036 13ACX−042 13ACX−048 13ACX−060
−2 units
Nominal Tonnage (kW) 1.5 (5.3) 2 (7.0) 2.5 (8.8) 3 (10.6) 3.5 (12.3) 4 (14.1) 5 (17.6)
Connections
(sweat)
Liquid line o.d. − in. (mm) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
(sweat)
Suction line o.d. − in. (mm) 3/4 (19.1)
3/4 (19.1) 3/4 (19.1) 7/8 (22.2) 7/8 (22.2) 7/8 (22.2) 1-1/8 (28.6)
1
Refrigerant (R-410A) furnished 4 lbs. 7 oz.
(2.01 kg)
4 lbs. 14 oz.
(2.21 kg)
6 lbs. 3 oz.
(2.81 kg)
6 lbs. 7 oz.
(2.92 kg)
8 lbs. 14 oz.
(4.03 kg)
8 lbs. 4 oz.
(3.74 kg)
**10 lbs. 0
oz. (4.54 kg)
Outdoor
Coil
Net face area
sq ft (m
2
)
Outer coil 13.22 (1.23) 15.11 (1.40) 13.22 (1.23) 13.22 (1.23) 15.11 (1.40) 16.33 (1.52) 21.0 (1.95)
Coil - sq. ft. (m
2
)
Inner coil − − − − − − 12.60 (1.17) 12.60 (1.17) 14.40 (1.34) 15.71 (1.46) 20.25 (1.88)
Tube diameter − in. (mm) 5/16 (8) 5/16 (8) 5/16 (8) 5/16 (8) 5/16 (8) 5/16 (8) 5/16 (8)
Number of rows 1 1 2 2 2 2 2
Fins per inch (m) 22 (866) 22 (866) 22 (866) 22 (866) 22 (866) 22 (866) 22 (866)
Outdoor
Fan
Diameter − in. (mm) 18 (457) 18 (457) 18 (457) 18 (457) 18 (457) 22 (559) 22 (559)
Fan
Number of blades 3 3 4 4 4 4 4
Motor hp (W) 1/5 (149) 1/5 (149) 1/5 (149) 1/5 (149) 1/3 (249) 1/4 (186) 1/4 (186)
Cfm (L/s) 2500 (1180) 2500 (1180) 2450 (1155) 2450 (1155) 2930 (1385) 3830 (1805) 3830 (1805)
Rpm 1100 1100 1100 1100 1100 825 825
Watts 200 200 200 200 310 330 330
Shipping Data − lbs. (kg) 1 package 122 (55) 129 (59) 150 (68) 150 (68) 177 (80) 201 (91) 222 (100)
ELECTRICAL DATA
Line voltage data − 60 hz − 1ph 208/230V 208/230V 208/230V 208/230V 208/230V 208/230V 208/230V
2
Maximum overcurrent protection (amps) 20 30 30 35 40 50 60
3
Minimum circuit ampacity 12.3 17.9 18.7 21.9 24.1 28.9 34.5
Compressor
Rated load amps 9.0 13.4 14.1 16.6 17.9 21.8 26.2
p
Power factor .96 .97 .98 .98 .94 .95 .98
Locked rotor amps 48 58 73 79 112 117 134
Condenser
Fan Motor
Full load amps 1.0 1.0 1.0 1.0 1.9 1.7 1.7
Fan Motor
Locked rotor amps 1.9 1.9 1.9 1.9 4.1 3.1 3.1
OPTIONAL ACcESSORIES − must be ordered extra
Compressor Crankcase
Ht
93M05    
p
Heater
31J20
  Factory
Compressor Hard Start Kit
10J42 
p
88M91      
Compressor Low Ambient Cut−Off 45F08       
Compressor Sound Cover 69J03       
Compressor Time−Off Control 47J27       
Freezestat
3/8 in. tubing 93G35       
1/2 in. tubing 39H29       
5/8 in. tubing 50A93       
Hail Guards
92M88   
92M89  
45M56 
92M94 
Loss of Charge Kit 84M23       
Low Ambient Kit 34M72       
Mounting Base
69J06     
g
69J07  
Refrigerant
Line Sets
L15−41−20, L15−41−30,
L15−41−40, L15−41−50
  
L15−65−30, L15−65−40,
L15−65−50
  
Field Fabricate 
Time Delay Relay Kit 58M81       
Unit Stand−Off Kit 94J45       
** Charge for −1 units 11 lbs 2 oz NOTE  Extremes of operating range are plus 10% and minus 5% of line voltage.
1
Refrigerant charge sufficient for 15 ft. (4.6 m) length of refrigerant lines.
2
HACR type circuit breaker or fuse.
3
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
