Lennox G21Q3-60 User Manual

Page 11
UNIT COMPONENTS UPFLOW Q" UNITS
AIR INTAKE PVC CONNECTION
IGNITION CONTROL
EXPANSION TANK
GAS VALVE
CONTROL BOX
LIMIT CONTROL
SPARK PLUG & SENSOR ACCESS
PANEL
BLOWER
GAS FLAPPER VALVE
& ORIFICE ASSEMBLY
EXHAUST OUTLET
TERMINAL STRIP
TB1
DOOR INTERLOCK SAFETY SWITCH
AIR FLAPPER VALVE
INSULATION
HEATING COMPARTMENT
PURGE BLOWER
DIFFERENTIAL PRESSURE
SWITCH
SPARK PLUG
& SENSOR ACCESS
PANEL
UNIT COMPONENTS HORIZONTAL/REVERSE FLOW V" UNITS
(ICM2 SHOWN WITH VSP2−1)
PURGE BLOWER
AIR INTAKE PVC CONNECTION
IGNITION
CONTROL
DIFFERENTIAL PRESSURE
SWITCH
EXPANSION
TANK
GAS VALVE
EXHAUST
OUTLET
AIR FLAPPER
VALVE
MODULATION/LIMIT
CONTROL
BLOWER
GAS FLAPPER VALVE
& ORIFICE ASSEMBLY
TERMINAL STRIP TB1
CONTROL
BOX
DOOR INTERLOCK
SAFETY SWITCH
INSULATION
HEATING
COMPARTMENT
VSP21
CONTROL BOARD
