G61MPVT − 50hz / Page 13
BLOWER DATA − 0 through 200 Pa External Static Pressure Range
G61MPVT−60C−110 BLOWER PERFORMANCE (less filter)
Single Side Return Air − Air volumes in bold require field fabricated transition to accommodate 508 x 635 x 25 mm cleanable
air filter in order to maintain proper air velocity across the filter.
"
Speed Switch Positions
Switch
Second Stage HEAT" Speed − L/s Second Stage COOL" Speed − L/s
Positions
1
1
2 3 4 1 2 3
1
4
+ 700 790 880 980 750 800 900 1010
1
NORM 635 720 815 895 675 725 820 910
555 630 710 790 605 655 740 830
ADJUST"
First Stage HEAT" Speed − L/s First Stage COOL" Speed − L/s
Switch
Positions
1
1
2 3 4 1 2 3
1
4
+ 625 710 800 880 440 485 545 605
1
NORM 565 645 730 810 395 430 495 555
510 570 645 720 355 375 435 495
G61MPVT−60D−135 BLOWER PERFORMANCE (less filter)
Bottom Return Air, Return Air from Both Sides or Return Air from Bottom and One Side.
"
Speed Switch Positions
Switch
Second Stage HEAT" Speed − L/s Second Stage COOL" Speed − L/s
Positions
1
1
2 3 4 1 2 3
1
4
+ 710 805 895 995 760 815 915 1035
1
NORM 645 730 820 905 685 745 840 935
580 650 730 810 615 660 755 840
ADJUST"
First Stage HEAT" Speed − L/s First Stage COOL" Speed − L/s
Switch
Positions
1
1
2 3 4 1 2 3
1
4
+ 655 740 830 910 535 570 645 725
1
NORM 590 670 750 835 485 520 580 655
535 595 675 750 430 465 525 580
1
Factory default jumper setting.
N/A − First and second stage HEAT positions shown cannot be used on this model.
NOTES − The effect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage
HEAT speed position.
First stage COOL (two−stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is approximately 38% of the same second stage COOL speed position − minimum 235 L/s.
