Lennox INNOVA DHADC Series User Manual

1
2
3
4
Page 44 - Application Guide INNOV@-0907
DHCDR
0300 0400 0500 0650 0900 1000
A 170 180 195
B 85 75 85
C 280 250 250
D 265 200 200
E 300 300 300
F 435 470 500
G 95 90 80
230 255 245
1" 1/4 1" 1/2 2"
1" 1/4 1" 1/2 2"
1 2 3
1010 1760 2510
Direct Expansion DX unit : DHCDR
OVERALL DIMENSIONS
FRONT VIEW
FRONT VIEW
LATERAL VIEW
A-A CROSS VIEW
TOP VIEW
FRONT VIEW
H
Liquid line inlet
Gaz line outlet
Frame
Length
Cooling Water Inlet
Cooling Water Outlet
Humidier Water Supply
Humidier Water Drain
