BLOWER DATA - DIRECT DRIVE - KGA/KGB036, KGA/KGB048
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (larger gas heat section, economizer, wet coil, etc.) See page 41.
2 - Any eld installed accessories air resistance (duct resistance, diffuser, etc.) See page 41.
External Static
Pressure (in. w.g.)
Air Volume (cfm) at Various Blower Speeds
208 VOLTS 230 VOLTS 460/575 VOLTS
High Medium Low High Medium Low High Medium Low
3 and 4 Ton Standard Efciency (Downow) KGA/KGB036S and KGA/KGB048S
0.0 1873 1561 1123 2094 1783 1321 2064 1727 1216
0.1 1993 1601 1148 2168 1797 1338 2105 1744 1229
0.2 1913 1601 1137 2098 1803 1308 2050 1694 1198
0.3 1858 1527 1078 2036 1725 1261 1987 1638 1167
0.4 1801 1496 1046 1973 1679 1219 1905 1598 1148
0.5 1763 1467 987 1910 1647 1177 1862 1559 1108
0.6 1709 1414 897 1830 1560 1080 1781 1509 1057
0.7 1617 1368 806 1727 1519 986 1698 1449 982
0.8 1472 1269 730 1604 1419 918 1614 1389 920
0.9 1359 1162 487 1478 1363 706 1488 1346 792
1.0 961 922 370 1093 1083 590 1167 1099 703
3 and 4 Ton Standard Efciency (Horizontal) KGA/KGB036S and KGA/KGB048S
0.0 1799 1530 1073 2012 1747 1263 2015 1756 1251
0.1 1868 1544 1088 2032 1733 1268 2071 1760 1279
0.2 1802 1494 1068 1976 1682 1228 2014 1700 1226
0.3 1735 1432 1014 1900 1618 1185 1937 1634 1187
0.4 1666 1397 980 1825 1568 1142 1878 1597 1174
0.5 1615 1350 904 1750 1516 1078 1801 1558 1124
0.6 1564 1305 842 1675 1440 1014 1743 1479 1060
0.7 1462 1228 758 1562 1364 928 1664 1415 982
0.8 1330 1151 670 1449 1287 842 1512 1335 865
0.9 1194 1011 464 1298 1185 671 1393 1297 733
1.0 878 878 355 998 1032 565 1060 1063 618
