Page 46
LGH/LCH156, 180, 210, 240, 300S
Supply Air Inverter Operation
This is a summary of cooling operation. Refer to the
sequence of operation provided in the Engineering
Handbook or Service Manual for more detail.
Note - During a dehumidification demand the blower
operates at the highest speed. Free cooling is locked-out
during reheat operation. Refer to reheat start-up and
operation section for details.
A-Two-Stage T'Stat; 3- and 4-Compressor Units
1-Economizer With Outdoor Air Suitable
Y1 Demand -
Compressors Off
Blower Cooling Low
Dampers modulate
Y2 Demand -
Compressors Off
Blower Cooling High
Dampers Modulate
156, 180H, 210, 240H, 300S - If dampers are at maximum
open for three minutes, compressor 1 and 2 are
energized and blower stays on cooling high.
180U, 240U - If dampers are at maximum open for three
minutes, two compressors (one from each circuit) are
energized and blower stays on cooling high.
2-No Economizer or Outdoor Air Not Suitable
Y1 Demand -
First-stage Compressors On
Blower Cooling Low
Dampers Minimum Position
Y2 Demand -
All Compressors On
Blower Cooling High
Dampers Minimum Position
B-Three-Stage T'Stat, 3 and 4 Compressor Units AND
Zone Sensor (4 Clg. Stages), 3-Compressor Units
1-Economizer With Outdoor Air Suitable
Three-Compressor Units:
Y1 Demand -
Compressors Off
Blower Cooling Low
Dampers Modulate
Y2 Demand -
Compressors Off
Blower Cooling High
Dampers Modulate
Note - If dampers are at maximum open for three minutes,
compressor 1 is energized and blower stays on cooling high.
Y3 Demand -
Compressors 1 and 2 On
Blower Cooling High
Dampers Maximum Open
Y4 Demand -
All Compressors On
Blower Cooling High
Dampers Maximum Open
Four-Compressor Units:
Y1 Demand -
Compressors Off
Blower Cooling Low
Dampers modulate
Y2 Demand -
Compressors Off
Blower Cooling High
Dampers Modulate
156, 180H, 210, 240H, 300S - If dampers are at maximum
open for three minutes, compressors 1 and 2 are
energized and blower stays on cooling high.
180U, 240U - If dampers are at maximum open for three
minutes, two compressors (one from each circuit) are
energized and blower stays on cooling high.
Y3 Demand -
Compressors 1, 2 and 3 On
(180U & 240U, any three compressors are on)
Blower Cooling High
Dampers Maximum Open
2-No Economizer or Outdoor Air Not Suitable
Three-Compressor Units:
Y1 Demand -
Compressor 1 On
Blower Cooling Low
Y2 Demand -
Compressors 1 and 2 On
Blower Cooling Medium
Y3 or Y4 Demand -
All Compressors On
Blower Cooling High
To Next Page
