Page 3
LGT/LCT036, 048, 060, 072
LGT036, 048, 060, & 072 PARTS ARRANGEMENT
8.8.8.8
EVAPORATOR
COIL
CONDENSER
FAN
CONDENSER
COIL
COMPRESSOR
CONDENSATE
DRAIN
FILTERS (4)
20 X 20 X 2”
ECONOMIZER
(OPTIONAL)
GAS VALVE
BURNERS
COMBUSTION
AIR INDUCER
BLOWER
(DIRECT DRIVE)
TXV
UNIT
CONTROLLER
REHEAT COIL
(OPTIONAL)
COIL
GUARDS
(OPTIONAL)
LCT036, 048, 060, & 072 PARTS ARRANGEMENT
8.8.8.8
ELECTRIC HEAT
(OPTIONAL)
EVAPORATOR
COIL
CONDENSER
FAN
CONDENSER
COIL
COMPRESSOR
CONDENSATE
DRAIN
ECONOMIZER
(OPTIONAL)
BLOWER
(DIRECT DRIVE)
FILTERS (4)
20 X 20 X 2”
TXV
UNIT
CONTROLLER
REHEAT COIL
(OPTIONAL)
COIL
GUARDS
(OPTONAL
