16
6.Function and Control
6.1 Introduction of Control Panel
After putting through the power, air conditioner will give out a sound and indicators on control panel will be on. After that, you operate the
air conditioner through remote controller or control panel.
Note:If wireless remote controller is lost, open the surface panel and operate manually.
-"OPEN" position,the ventilation door
opens to allow air,smoke or odors to
be expelled from the room.
-"CLOSE" position,the ventilation door
is closed and the air will be circulated
inside the room and conditioned.
VENTILATION LEVER
Ventilation Lever
When the slider at the:
When the slider at the:
1
P O W E R B U T T O N
O p e r a t i o n s t a r t s w h e n p r e s s i n g t h i s b u t t o n , a n d s t o p s
w h e n p r e s s i n g t h i s b u t t o n a g a i n .
2
F A N SPEED B U T T O N
S e l e c t t h e f a n s p e e d H I G H , M ID , L O W and AUTO i n s e q u e n c e .
3
P r e s s t h e k e y p a d a l s o t o i n c r e a s e t h e s e l e c t e d t i m e
i n 1 h o u r i n c r e m e n t s , a n d P r e s s t h e k e y p a d t o
d e c r e a s e t h e s e l e c t e d t i m e i n 1 h o u r d e c r e m e n t s , T h e 
t i m e s e t i n g r a n g e i s f r o m 0 ~ 2 4 h o u r s .
4
TEMP/TIMER BUTTON
Press the keypad to increase the set (operating)
t e m p e r a t u r e o f t h e u n i t . a n d P r e s s t h e k e y p a d t o
d e c r e a s e t h e s e t ( o p e r a t i n g ) t e m p e r a t u r e o f t h e u n i t .
T h e t e m p e r a t u r e s e t i n g r a n g e i s f r o m 1 6 ~ 3 0 ć
MOD E B U T T O N
Select the operation mode, AUTO, HEAT, COOL, FAN, DRY.
5
S I G N A L R E C E I V E R
6
S W I N G B U T T O N
A c t i v a t e t h e a u t o m a t i c a i r s w i n g f u n c t i o n .
7
FILTER BUTTON
This feature is a reminder to clean the Air Filter (See
Care and Cleaning) for more efficient operation and
cooling. The LED (light) will illuminate after 250 hours
"Check Filter" button and the light will go off.
of operation. To reset after cleaning the filter, press the
CLOSE VENT OPEN CLOSE VENT OPEN
