Fan speed indication
Mode display
Displayedwhendatatransmitted.
DisplayedwhenremotecontrollerisON.
Batterydisplay (low batterydetection)
Lowspeed
Medium speed
High speed
Auto fanspeed
DisplayedwhenTIMER ON time is set.
DisplayedinSleep Mode operation.
Indicatedthat the air conditioneris
operatinginFollowmemode
DisplayedwhenTIMER OFFtimeisset.
Show settemperature or room
temperatu re, or time underTIMER
setting.
AUTO
HEAT FA N
COOL DRY
Note - During unit operation only the active functions
will be shown on the display.
Auto
1. PresstheMODE button to select Auto.
2. PresstheUP/DOWNbuttontosetthedesiredtemperature.Thetemperaturecan
besetwithinarangeof
3. PresstheON/OFFbuttontostarttheairconditioner.
Cooling /Heating/Fan
1. PresstheMODE button to select COOL, HEAT or FAN mode.
2. PresstheUP/DOWN buttonstosetthedesiredtemperature.
3. PresstheFANbuttontoselectthefanspeedinfoursteps-Auto,Low,Med,orHigh.
4. PresstheON/OFFbuttontostarttheairconditioner.
Dehumidifying
1. PresstheMODE button to select DRY mode.
2. PresstheUP/DOWNbuttonstosetthedesiredtemperature.
3. PresstheON/OFFbuttontostarttheairconditioner.
Timer ON/OFF
1. PresstheTIMER ON or TIMER OFFbutton.TheremotecontrollershowsTIMER
ONorTIMEROFFicon,thepreviousAuto-ontimesettingandthesignal“H”willbe
shownontheLCDdisplayarea.
2. PushtheTIMER ON or TIMER OFFbuttonagaintosetdesiredtime.Eachtime
youpressthebutton,thetimeincreasesby30minutesbetween0and10hours
andby60minutesbetween10and24hours.
3. AftersettingtheTIMER ON or TIMER OFFtherewillbeaoneseconddelaybefore
theremotecontroltransmitsthesignaltotheunit.Afterapproximately2seconds,
thesignal“H” will disappearand the settemperaturewill re-appear onthe LCD
displaywindow.
