Lennox MLB Series User Manual

6
?? (??)
TOP VIEW
FRONT VIEW
SIDE VIEW
?? (??)
?? (??)
15
(381)
13-3/4
(349)
12-3/4
(324)
35-1/4 (895)
2-3/8 (60)
4-1/4
(108)
13-1/2 (343)
26-1/2
(673)
1/2 (13)
?? (??)
DRAIN HOLE
(Bottom of Unit)
GAS VALVE
LIQUID VALVE
2-7/8 (73)
35 (889)
26-1/8 (664)
37-5/8 955)
Figure 3. MPC018S4S Outdoor Unit Dimensions - Inches (mm)
TOP VIEW
FRONT VIEW
SIDE VIEW
37-1/4 (946)
26-1/2 (673)
40-1/2 (1029)
GAS VALVE
LIQUID VALVE
2-3/8 (60)
4-1/4
(108)
3-5/8 (92)
18-1/8 (460)
18
(457)
15-7/8
(403)
DRAIN HOLE
(Bottom of Unit)
31-7/8
(810)
15-1/4
(387)
16-1/8 (410)
2-7/8 (73)
1 (25)
Figure 4. MPC024S4S Outdoor Unit Dimensions - Inches (mm)
