Wall Mounting Plates
Indoor unit outline
C
A
Right rear side
refrigerant pipe inlet
2-1/2 (64) diameter
2
(51)
Left rear side
refrigerant pipe inlet
2-1/2 (64) diameter
B
4-3/4
(121)
1-5/8
(41)
1-5/8
(41)
2
(51)
Size
A B C
in. mm in. mm in. mm
MWMC006, 009 11-1/2 290 28-1/2 724 13-3/4 349
MWMC012 11-3/4 297 31-3/4 806 15-7/8 403
Figure 8. MWMC06S4S, MWMC09S4S and MWMC012S4S Indoor Unit Wall Plate Dimensions - Inches (mm)
Φ
FROM EDGE TO HOLE CENTER:50mm
FROM EDGE TO HOLE CENTER:95mm
150
100
100
100
50
50
50
2
2
2
4
4
4
6
RECOMMAND
LIQUID
GAS
BUBBLE
LEVEL
mm
inch
mm
inch
Indoor unit outline
Right rear side
refrigerant pipe inlet
2-1/2 (64) diameter
Left rear side
refrigerant pipe inlet
2-1/2 (64) diameter
1-5/8
(41)
3-3/4
(95)
1-5/8 (41)
12-5/8
(321)
19-1/4 (489)
2
(51)
38 (965)
Figure 9. MWMC018S4S Indoor Unit Wall Plate Dimensions - Inches (mm)
